Douglas XP-48

XP-48

Role: Fighter aircraft
National origin: United States
Manufacturer: Douglas Aircraft Company
Status: Cancelled 1940
Primary user: United States Army Air Corps
Number built: None

The Douglas XP-48 was a small, lightweight fighter aircraft, designed by Douglas Aircraft in 1939 for evaluation by the U.S. Army Air Corps. Intended to be powered by a small inline piston engine, the contract was cancelled before a prototype could be constructed, due to the Army's concerns about the projected performance of the aircraft.

Inspiration

In the years before the outbreak of World War II, a number of countries became intrigued by the idea of developing a very light fighter aircraft, with these proposals often being derived from the design of racing aircraft. Following the consideration of a modified French Caudron racer by the U.S. Army Air Corps, a proposition that was considered uneconomical, Douglas Aircraft made an unsolicited proposal to the Army Air Corps of their Model 312 design in 1939.

Design and cancellation

Intended to be powered by a Ranger XV-770 inverted V-12 engine equipped with a supercharger, Douglas' proposal was considered as being worth pursuing by the Army Air Corps, and on 5 August 1939 a single prototype was ordered. The Model 312 was given the Army designation XP-48, the 48th aircraft type in the Pursuit category.

Closely resembling the later Bell XP-77, the design of the XP-48 featured a wing of remarkably high aspect ratio, and was equipped with a pair of synchronized machine guns for armament, Douglas touted the XP-48 as offering outstanding performance, with a top speed of at least 350 miles per hour (560 km/h), and, according to Douglas' estimates, possibly as high as 525 miles per hour (845 km/h).

However, this very aspect of its design was regarded by suspicion by the Army Air Corps. The Ranger engine was suffering from development difficulties and delays and would never prove truly reliable. At the same time, Douglas' performance estimates were becoming increasingly regarded as being over-optimistic. Accordingly, in February 1940 the Army cancelled the XP-48 contract, and without the government funding, Douglas ceased development of the aircraft.

Specifications (XP-48)

Data from

General characteristics

Crew: 1 (pilot)
Length: 21 ft 9 in (6.63 m)
Wingspan: 32 ft (9.8 m)
Height: 9 ft (2.7 m)
Wing area: 92 sq ft (8.5 m)
Empty weight: 2,675 lb (1,213 kg)
Gross weight: 3,400 lb (1,542 kg)
Fuel capacity: 50 US gallons (190 l; 42 imp gal)
Powerplant: 1 x— Ranger SGV-770 inverted V-12 liquid-cooled piston engine, 525 hp (391 kW)
Propellers: 3-bladed, 9.5 ft (2.9 m) diameter

Performance

Maximum speed: 525 mph (845 km/h; 456 kn)

Armament

Guns: 1 .30-caliber and 1 .50-caliber machine guns.

Comparable aircraft

Bell XP-77
Caudron C.714
Miles M.20
Tucker XP-57

Bibliography

Adcock, Al. OS2U Kingfisher in action. Carrollton, Texas: Squadron/Signal Publications, 1991. ISBN 0-89747-270-5.
Angelucci, Enzo. The American Fighter from 1917 to the present. New York: Orion, 1987. ISBN 0-517-56588-9.
Brown, Kimbrough. et. al. U.S. Army and Air Force Fighters, 1916-1961. Letchworth, England: Harleyford Publications, 1961. ASIN B001YTWMPC
Francillon, René J. McDonnell Douglas Aircraft since 1920. London: Putnam & Company Ltd., 1979. ISBN 0-370-00050-1.
Norton, Bill. U.S. Experimental & Prototype Aircraft Projects: Fighters 1939-1945. North Branch, Minnesota: Specialty Press, 2008. ISBN 978-1-58007-109-3.

Douglas XP-48 Pictures
