Fokker D.VII

Fokker D.VII

Warbird - Fokker D.VII

Role: Fighter
Manufacturer: Fokker-Flugzeugwerke
Designed by: Reinhold Platz
First flight: January 1918
Primary user: Luftstreitkrx¤fte
Number built: approximately 3,300

The Fokker D.VII was a German World War I fighter aircraft designed by Reinhold Platz of the Fokker-Flugzeugwerke. Germany produced around 3,300 D.VII aircraft in the summer and autumn of 1918. In service, the D.VII quickly proved itself to be a formidable aircraft. The Armistice ending the war specifically required Germany to surrender all D.VIIs to the Allies at the conclusion of hostilities. Surviving aircraft saw continued widespread service with many other countries in the years after World War I.

Development and production

Aircraft Picture - Fokker D.VII

Picture - Fokker D.VII

Fokker's chief designer, Reinhold Platz, had been working on a series of experimental planes, the V-series, since 1916. These planes were characterized by the use of cantilever wings, first developed during Fokker's government-mandated collaboration with Hugo Junkers. Junkers had originated the idea in 1915 with the first all-metal aircraft, the Junkers J 1, nicknamed Blechesel ("Sheet Metal Donkey" or "Tin Donkey"). The resulting wings were thick, with a rounded leading edge. This gave greater lift and more docile stalling behavior than conventional thin wings.

Late in 1917, Fokker built the experimental V 11 biplane, fitted with the standard Mercedes D.IIIa engine. In January 1918, Idflieg held a fighter competition at Adlershof. For the first time, frontline pilots would directly participate in the evaluation and selection of new fighters. Fokker submitted the V 11 along with several other prototypes. Manfred von Richthofen flew the V 11 and found it tricky, unpleasant, and directionally unstable in a dive. In response to these complaints, Reinhold Platz lengthened the rear fuselage by one structural bay, and added a triangular fixed vertical fin in front of the rudder. Upon flying the modified V 11, Richthofen praised it as the best aircraft of the competition. It offered excellent performance from the outdated Mercedes engine, yet it was safe and easy to fly. Richthofen's recommendation virtually decided the competition, but he was not alone in recommending it. Fokker immediately received a provisional order for 400 production aircraft, which were designated D.VII by Idflieg.

Aircraft Picture - Fokker D.VII(F)

Picture - Fokker D.VII(F)

Fokker's factory was not up to the task of meeting all D.VII production orders. Idflieg therefore directed Albatros and AEG to build the D.VII under license, though AEG did not ultimately produce any aircraft. Because the Fokker factory did not use detailed plans as part of its production process, Fokker simply sent a completed D.VII airframe for Albatros to copy. Albatros paid Fokker a five percent royalty for every D.VII built under license. Albatros Flugzeugwerke and its subsidiary, Ostdeutsche Albatros Werke (OAW), built the D.VII at factories in Johannisthal (designated Fokker D.VII (Alb)) and Schneidemx¼hl (Fokker D.VII (OAW)), respectively. Aircraft markings included the type designation and factory suffix, immediately before the individual serial number.

Some parts were not interchangeable between aircraft produced at different factories, even between Albatros and OAW. Additionally each manufacturer tended to differ in nose paint styles. OAW produced examples were delivered with distinctive mauve and green splotches on the cowling. All D.VIIs were produced with the lozenge camouflage covering except for early Fokker-produced D.VIIs, which had a streaked green fuselage. Factory camouflage finishes were often overpainted with colorful paint schemes or insignia for the Jasta, or the individual pilot.

Albatros soon surpassed Fokker in the quantity and workmanship quality of aircraft produced. With a massive production program, over 3,000 to 3,300 D.VII aircraft were delivered from all three plants, considerably more than the commonly quoted but incorrect production figure of 1,700.

In September 1918, eight D.VIIs were delivered to Bulgaria. Late in 1918, the Austro-Hungarian company MxG (Magyar xltalx¡nos Gépgyx¡r - Hungarian General Machine Company) commenced licensed production of the D.VII with Austro-Daimler engines. Production continued after the end of the war, with as many as 50 aircraft completed.

Powerplants

Aircraft Picture - Hermann Gx¶ring's Fokker D.VII(F) (serial 5125/18)

Picture - Hermann Gx¶ring's Fokker D.VII(F) (serial 5125/18)

Many sources erroneously state that the D.VII was equipped with the 160 hp Mercedes D.III engine. The Germans themselves used the generic D.III designation to describe later versions of that engine. In fact, the earliest production D.VIIs were equipped with 170-180 hp Mercedes D.IIIa. Production quickly switched to the intended standard engine, the higher-compression 134 kW (180 hp) Mercedes D.IIIax¼. It appears that some of the early production D.VIIs delivered with the D.IIIa were later re-engined with the D.IIIax¼.

By the summer of 1918, a number of D.VIIs received the "overcompressed" 138 kW (185 hp) BMW IIIa, the first product of the BMW firm. The BMW IIIa followed the SOHC, straight-six configuration of the Mercedes D.III, but incorporated several improvements. Increased displacement, higher compression, and an alititude-adjusting carburetor produced a marked increase in speed and climb rate at high altitude. Because the BMW IIIa was overcompressed, using full throttle at altitudes below 2,000 m (6,700 ft) risked premature detonation in the cylinders and damage to the engine. At low altitudes, full throttle could produce up to 179 kW (240 hp) for a short time. Fokker-built aircraft with the new BMW engine were designated D.VII(F), the suffix "F" standing for Max Friz, the engine's designer. Some Albatros-built aircraft may also have received a separate designation.

BMW-engined aircraft entered service with Jasta 11 in late June 1918. Pilots clamored for the D.VII(F), of which about 750 were built. However, production of the BMW IIIa was very limited and the D.VII continued to be produced with the 134 kW (180 hp) Mercedes D.IIIax¼ until the end of the war. With the D.IIIax¼, the D.VII was a very competitive fighter, but with the BMW IIIa, it was superlative.

D.VIIs flew with different propeller designs from different manufacturers. Despite the differing appearances there is no indication these propellers gave disparate performance. Axial, Wolff, Wotan, and Heine propellers have been noted.

Operational history

Aircraft Picture - Fokker D.VII of Jasta 66

Picture - Fokker D.VII of Jasta 66

The D.VII entered squadron service with Jasta 10 in early May 1918. The type quickly proved to have many important advantages over the Albatros and Pfalz scouts. Unlike the Albatros scouts, the D.VII could dive without any fear of structural failure. The D.VII was also noted for its ability to climb at high angles of attack, its remarkably docile stall, and its reluctance to spin. It could literally "hang on its prop" without stalling for brief periods of time, spraying enemy aircraft from below with machine gun fire. These handling characteristics contrasted with contemporary scouts such as the Camel and SPAD, which stalled sharply and spun vigorously.

However, the D.VII also had problems. Several aircraft suffered rib failures and fabric shedding on the upper wing. Heat from the engine sometimes ignited phosphorus ammunition until cooling vents were installed in the engine cowling, and fuel tanks sometimes broke at the seams. Aircraft built by the Fokker factory at Schwerin were noted for their lower standard of workmanship and materials. Nevertheless, the D.VII proved to be a remarkably successful design, leading to the familiar aphorism that it could turn a mediocre pilot into a good one, and a good pilot into an ace.

Manfred von Richthofen died only days before the D.VII began to reach the Jagdstaffeln and never flew it in combat. Other pilots, including Erich Lx¶wenhardt and Hermann Gx¶ring, quickly racked up victories and generally lauded the design. Aircraft availability was limited at first, but by July there were 407 on charge. Larger numbers became available by August, when D.VIIs achieved 565 victories. The D.VII eventually equipped 46 Jagdstaffeln. When the war ended in November, 775 D.VII aircraft were in service.

Postwar service

Aircraft Picture - Preserved D.VII in Swiss markings

Picture - Preserved D.VII in Swiss markings

The Allies confiscated large numbers of D.VII aircraft after the Armistice. The United States Army and Navy evaluated 142 captured examples. Several of these aircraft were reengined with American-built Liberty L-6 motors, very similar in appearance to the D.VII's original German powerplants. France, Great Britain, and Canada also received numbers of war prizes.

Other countries used the D.VII operationally. The Polish deployed approximately 50 aircraft during the Polish-Soviet War, using them mainly for ground attack missions. The Hungarian Soviet Republic used a number of D.VIIs, both built by MAG and ex-German aircraft in the Hungarian-Romanian War of 1919.

The Dutch, Swiss and Belgian air forces also operated the D.VII. The aircraft proved so popular that Fokker completed and sold a large number of D.VII airframes that he had smuggled into the Netherlands after the Armistice. As late as 1929, the Alfred Comte company manufactured eight new D.VII airframes under licence for the Swiss Fliegertruppe.

Survivors

Aircraft Picture - Fokker D.VII preserved in the Deutsches Museum

Picture - Fokker D.VII preserved in the Deutsches Museum

The widespread acquisition of the D.VII by Allied countries after the Armistice ensured the survival and preservation of several aircraft. One war prize was captured in 1918 when it accidentally landed at a small American airstrip near Verdun, France. Donated to the Smithsonian Institution by the War Department in 1920, it is now displayed at the National Air And Space Museum in Washington, D.C. Two other American war prizes were retained by private owners until sold abroad in 1971 and 1981. They are today displayed at the Canada Aviation Museum, in Ottawa, Ontario, and the Militaire Luchtvaart Museum in Soesterberg, Netherlands, respectively. The latter aircraft is painted in fictitious Royal Netherlands Air Force markings.

A former Marine Luchtvaartdienst D.VII was discovered in a German barn in 1948. This aircraft is now displayed at the Deutsches Museum in Munich, Germany.

Aircraft Picture - Fokker D.VII displayed at the Royal Air Force Museum

Picture - Fokker D.VII displayed at the Royal Air Force Museum

Both Canada and France also acquired numerous D.VII aircraft. A former war prize, one of 22 acquired by Canada, is displayed at the Brome County Historical Society, in the Knowlton neighborhood of Lac-Brome, Quebec. This unrestored Albatros-built example is the only surviving D.VII that retains its original fabric covering. Of the aircraft sent to France, examples are today displayed at the Royal Air Force Museum in Hendon, England, and the Musée de l'Air et de l'Espace in Paris, France.

Replicas

Many modern D.VII replicas have been built. Most flyable examples are powered by Ranger or Gypsy Queen inverted inline engines. These engines must be turned upright to produce the correct thrust line, thus requiring a new oiling system. A few flying replicas are equipped with original Mercedes D.III engines.

Variants

V 11 : Prototype
V 21 : Prototype with tapered wings
V 22 : Prototype with four-bladed propeller
V 24 : Prototype with 179 kW (240 hp) Benz Bz.IVx¼ engine
V 31 : One D.VII aircraft fitted with a hook to tow the V 30 glider
V 34 : D.VII development with 138 kW (185 hp) BMW IIIa engine
V 35 : Two-seat development with 138 kW (185 hp) BMW IIIa engine and undercarriage fuel tank
V 36 : D.VII development with 138 kW (185 hp) BMW IIIa engine and undercarriage fuel tank
V 38 : Prototype Fokker C.I

Operators

Aircraft Picture - Interned Fokker D.VII in Swiss markings

Picture - Interned Fokker D.VII in Swiss markings

Specifications

General characteristics

Crew: One
Length: 22 ft 9 in (6.93 m)
Wingspan: 29 ft 3 in (8.93 m)
Height: 9 ft 2 in (2.80 m)
Wing area: 217.4 ft² (20.2 m²)
Empty weight: 1,540 lb (698 kg)
Loaded weight: 1,874 lb (850 kg)
Max takeoff weight: 1,936 lb (878 kg)
Powerplant: 1x— Mercedes D.IIIa or au or BMW, 170hp/230 depending on engine (134 kW)

Performance

Maximum speed: 116 mph 170hp Merecedes D.IIIa (early), faster with 180hp DIIIau, 124 mph BMW (185/230hp)
Service ceiling: 19,600 ft (5,970 m)
Rate of climb: 787 ft/min (240 m/min)
Wing loading: 9.64 lb/ft² (47 kg/m²)

Armament

2 x— 7.92 mm (.312 in) LMG 08/15 "Spandau" machine guns

Related development

Fokker C.I

Comparable aircraft

Pfalz D.XII
Pfalz D.XV
Martinsyde Buzzard
Ansaldo Balilla

Bibliography

Gray, Peter and Owen Thetford. German Aircraft of the First World War. London: Putnam, 1962.
Owers, Colin. ""Especially... The D.VII...": The post-1918 career of the Fokker D.VII: Part One". Air Enthusiast, No. 60, November-December 1995, pp. 63-70. ISSN 0143-5450.
Owers, Colin. ""Especially... The D.VII...": The post-1918 career of the Fokker D.VII: Part Two". Air Enthusiast, No. 61, January-February 1996, pp. 52-63. ISSN 0143-5450.
Swanborough, Gordon and Peter M. Bowers. United States Military Aircraft since 1908. London: Putnam, 1963.
Weyl, A.R. Fokker: The Creative Years. London: Putnam, 1988. ISBN 0-85177-817-8.
